Transport achor screw

High-quality steel, with AG tip

  • AG screw tip

The secure lifting system
Made of quality steel, this manual lifting attachment is used to lift all kinds of timber parts securely and easily. The transport anchors of the load group of up to 1.3 tonnes are expressly to be used only in conjunction with the Ø 11 x 160 mm Eurotec transport anchor screw tested in the ETA-11/0024 European Technical Approval. The Ø 11 x 160 Eurotec transport anchor screw is only to be used once! It can be screwed into solid wood (softwood), laminated veneer lumber, glue-laminated timber, composite laminated board and composite laminated beam without pilot-drilling. Use in hardwoods is not permitted! The possible and/or approved assembly positions can be found in our operating instructions. We will be delighted to provide you with a copy of these.
Please note:

  • Transport anchor screws must only be used once
  • Read the operating instructions in detail before use
  • Users are to be trained prior to the first commissioning
  • The transport anchor is to be examined for damage before each use and discarded where appropriate
  • The weights of the parts to be lifted must be known and permissible
  • Only the lifting equipment stated in the operating instructions may be used

How the system works:

  1. Screw in the screw without pilot-drilling
  2. Engage the anchor
  3. Lift the load
  4. Release the anchor
  5. Release the anchor

Product table

Art. no. Dimension Drive Tensile strength PU EAN
110359 11,0 x 125 mm SW 17 min. 1200 N/mm² 20 Pieces 4251314718556
110360 11,0 x 160 mm SW 17 min. 1200 N/mm² 20 Pieces 4250207490098
