Paneltwistec AG countersunk head screw

Beschreibung

Paneltwistec AG countersunk head screw

special coated

Europ. Techn. Assessment: ETA-11/0024

Generic type and use of construction product:

Wood construction screws

Open PDF

Download

Datenblätter


Product data sheet – Paneltwistec AG

CAD data


DWG data PT AG countersunk head screw

Art. no. Dimensions Drive PU EAN
945436 3,5 x 30 mm TX15 1000 4250207449942
945838 3,5 x 35 mm TX15 1000 4250207463405
945437 3,5 x 40 mm TX15 1000 4250207449959
945490 3,5 x 50 mm TX15 500 4250207449973
945491 4,0 x 30 mm TX20 1000 4250207449980
945836 4,0 x 35 mm TX20 1000 4250207463351
945492 4,0 x 40 mm TX20 1000 4250207449997
945493 4,0 x 45 mm TX20 500 4250207450009
945494 4,0 x 50 mm TX20 500 4250207450016
945495 4,0 x 60 mm TX20 200 4250207450023
945496 4,0 x 70 mm TX20 200 4250207450030
945497 4,0 x 80 mm TX20 200 4250207450047
945498 4,5 x 40 mm TX25 500 4250207450054
945588 4,5 x 45 mm TX25 500 4250207458388
945499 4,5 x 50 mm TX25 500 4250207429302
945567 4,5 x 60 mm TX25 200 4250207429319
945568 4,5 x 70 mm TX25 200 4250207429326
945569 4,5 x 80 mm TX25 200 4250207429333
945574 5,0 x 40 mm TX25 200 4250207450061
945837 5,0 x 45 mm TX25 200 4250207463399
945575 5,0 x 50 mm TX25 200 4250207429364
945576 5,0 x 60 mm TX25 200 4250207429371
945577 5,0 x 70 mm TX25 200 4250207429388
945578 5,0 x 80 mm TX25 200 4250207429395
945579 5,0 x 90 mm TX25 200 4250207429401
945580 5,0 x 100 mm TX25 200 4250207429340
945581 5,0 x 120 mm TX25 200 4250207429357
945583 6,0 x 60 mm TX30 200 4250207429524
945584 6,0 x 70 mm TX30 200 4250207429531
945632 6,0 x 80 mm TX30 200 4250207429548
945633 6,0 x 90 mm TX30 100 4250207429555
945634 6,0 x 100 mm TX30 100 4250207429418
945635 6,0 x 110 mm TX30 100 4250207450078
945636 6,0 x 120 mm TX30 100 4250207429425
945637 6,0 x 130 mm TX30 100 4250207450085
945638 6,0 x 140 mm TX30 100 4250207429432
945639 6,0 x 150 mm TX30 100 4250207450092
945640 6,0 x 160 mm TX30 100 4250207429449
945641 6,0 x 180 mm TX30 100 4250207429456
945642 6,0 x 200 mm TX30 100 4250207429463
945643 6,0 x 220 mm TX30 100 4250207429470
945644 6,0 x 240 mm TX30 100 4250207429487
945645 6,0 x 260 mm TX30 100 4250207429494
945646 6,0 x 280 mm TX30 100 4250207429500
945647 6,0 x 300 mm TX30 100 4250207429517
945687 10 x 100 mm TX50 50 4250207450115
945688 10 x 120 mm TX50 50 4250207450122
945689 10 x 140 mm TX50 50 4250207450139
945690 10 x 160 mm TX50 50 4250207450146
945691 10 x 180 mm TX50 50 4250207450153
945692 10 x 200 mm TX50 50 4250207450160
945693 10 x 220 mm TX50 50 4250207450177
945694 10 x 240 mm TX50 50 4250207450184
945695 10 x 260 mm TX50 50 4250207450191
945696 10 x 280 mm TX50 50 4250207450207
945697 10 x 300 mm TX50 50 4250207450214
945698 10 x 320 mm TX50 50 4250207450221
945699 10 x 340 mm TX50 50 4250207450238
945703 10 x 360 mm TX50 50 4250207450245
945709 10 x 380 mm TX50 50 4250207450252
945711 10 x 400 mm TX50 50 4250207450269
