ERD SK frame fixing, countersunk head
Set consisting of plug and screw
The EuroTec countersunk/cylinder-head frame fixing can be used for multiple fastenings of, e.g., façade substructures in concrete and brickwork. It consists of a plastic plug and an electrogalvanised countersunk screw (TX 40) / hexagon screw (AF 13).
Advantages:
- Through-hole mounting
- Ready for loading immediately
- The hammer-in stop prevents premature expansion of the plug during installation
Product table
| Art. no. | Dimension | Drive | PU | EAN |
|---|---|---|---|---|
| 200012 | 10,0 x 80 mm | TX 40 | 50 Pieces | 4250207470113 |
| 200013 | 10,0 x 100 mm | TX 40 | 50 Pieces | 4250207470021 |
| 200014 | 10,0 x 120 mm | TX 40 | 50 Pieces | 4250207470038 |
| 200015 | 10,0 x 140 mm | TX 40 | 50 Pieces | 4250207470045 |
| 200016 | 10,0 x 160 mm | TX 40 | 50 Pieces | 4250207470052 |
| 200017 | 10,0 x 180 mm | TX 40 | 50 Pieces | 4250207470069 |
| 200018 | 10,0 x 200 mm | TX 40 | 50 Pieces | 4250207470076 |
| 200019 | 10,0 x 230 mm | TX 40 | 25 Pieces | 4250207470083 |
| 200020 | 10,0 x 260 mm | TX 40 | 25 Pieces | 4250207470106 |
